Mesh Antennas
Browse and compare antennas for mesh networking devices.
These tests results and suggestions are primarily from the Austin Mesh community by way of both VNA testing and real world use on the mesh. Add your test results here.
Sort By
Categories
Connector Type
Frequency
Status
Price Range
$
to$
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.329:1
Connector: SMA Male
Gain: 10 dBi(there is no way this is true)
$6.80 - $15.99
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.057:1
Connector: N-Type Male
Gain: 5 dBi
$13.85 - $17.99
View Details
Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): 1.013:1
Connector: N-Type Male
Gain: 5.8 dBi
$39.97
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.047:1
Connector: N-Type Female
Gain: 6 dBi
$29.97
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.179:1
Connector: N-Type Female
Gain: 13.2 dBi
$41.95 - $53.55
View Details
Suggested
Frequency: 915 MHz
VSWR (915MHz): 1.172:1
Connector: SMA Male
Gain:
$11.90 - $11.99
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.643:1
Connector: N-Type Male
Gain: 3 dBi
$25.00
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.480:1
Connector: SMA Male
Gain: 3.5 dBi
$1.33 - $8.99
View Details
Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): N/A
Connector: SMA Male
Gain: 5 dBi
$6.15
View Details
Not Suggested
Frequency: 862-876 MHz
VSWR (915MHz): N/A
Connector: SMA Male
Gain: 12 dBi(exaggerated)
$3.44
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.460:1
Connector: RP-SMA Male
Gain: 5.8 dBi
$26.99
View Details
Suggested
Frequency: 915 MHz
VSWR (915MHz): 1.484:1
Connector: SMA Male
Gain: 10 dBi (claimed)
$16.99
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 2.450:1
Connector: u.FL/IPEX
Gain: Unknown
$17.99
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.933:1
Connector: SMA Male
Gain: Unknown
$17.99
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.124:1
Connector: N-Type Female
Gain: 8 dBi
$56.99
View Details
Not Suggested
Frequency: 905-920 MHz
VSWR (915MHz): 2.365:1
Connector: SMA Male
Gain: 2 dBi
$4.63
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.506:1
Connector: N-Type Male
Gain: 5.5 dBi
$18.16 - $21.15
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 6.278:1
Connector: SMA Male
Gain: Unknown
$29.02
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 3.677:1
Connector: SMA Male
Gain: Unknown
$0.00
View Details
Not Suggested
Frequency: 750-950 MHz
VSWR (915MHz): 1.759:1
Connector: RP-SMA Male
Gain: 1.6 dBi
$10.00
View Details
Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): 1.704:1
Connector: u.FL/IPEX
Gain: <0 dBi
$4.66 - $6.16
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.736:1
Connector: SMA Male
Gain: 1.2 dBi
$8.60 - $15.54
View Details
Not Suggested
Frequency: 915 MHz
VSWR (915MHz): 2.544:1
Connector: SMA Male
Gain: 5 dBi (claimed)
$11.99
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.538:1
Connector: SMA Male
Gain: 4 dBi
$10.49 - $10.50
View Details
Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): 1.551:1
Connector: u.FL/IPEX
Gain: 1.3 dBi
$1.89 - $3.76
View Details
Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): 1.332:1
Connector: SMA Male
Gain: 1 dBi
$8.51 - $9.33
View Details
Suggested
Frequency: 900-930 MHz
VSWR (915MHz): 1.215:1
Connector: N-Type Male
Gain: 3 dBi
$27.50 - $38.97
View Details
Suggested
Frequency: 900-930 MHz
VSWR (915MHz): 1.955:1
Connector: N-Type Male
Gain: 8 dBi
$60.00
View Details
Not Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): 2.088:1
Connector: N-Type Male
Gain: 5 dBi
$35.00
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.210:1
Connector: N-Type Male
Gain: 5 dBi (with ground plane)
$16.73 - $23.56
View Details
Suggested
Frequency: 862-876 MHz, 902-928 MHz
VSWR (915MHz): 1.202:1
Connector: RP-SMA Male
Gain: 3.3 dBi
$6.54 - $6.63
View Details
Suggested
Frequency: 910-920 MHz
VSWR (915MHz): 1.151:1
Connector: SMA Male
Gain: 5 dBi
$13.99
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.178:1
Connector: SMA Male
Gain: 3 dBi
$11.99
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 3.680:1
Connector: RP-SMA Male
Gain: Unknown
$39.90
View Details
Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 1.17:1
Connector: N-Type Male
Gain: 7 dBi
$25.37
View Details
Not Suggested
Frequency: 902-928 MHz
VSWR (915MHz): 8.670:1
Connector: SMA Male
Gain: 3 dBi
$2.30 - $5.00
View DetailsMissing an antenna?
Know an antenna that should be listed here? Suggest it and we will add it.
